Features
- Heavy-duty design allows for a variety of precision drilling applications
- Full power to the cutting tools through 6 speed geared head
- CSA/CUS: Following strict guidelines and electrical requirements, this JET Mill Drill is CSA/CUS certified
- Spindle guard
- Work Lamp
- Calibrated fine down feed built in
- Easy to read internal depth gauge
- Head tilts left and right 90-Degrees
- Rapid spindle speed changes through quick-select gear shift levers
- Forward/reverse switch
- Milling table allows for movement
- R8 spindle allows use of all mill tooling
What's in The Box
- 1-1/2-Inch Geared Head Mill/Drill
- Owner's Manual
Warranty
- JET Red Assurance 2-Year Warranty
- 30 Day Satisfaction Guaranteed
Specifications
Sku | 351040 |
Brand | Jet |
Voltage | 115/230v |
Horsepower | 1-1/2 Hp |
Phase | 1-Phase |
Drilling Capacity | 1-1/2 in. Mild Steel |
Face Mill Capacity | 4 in. |
End Mill Capacity | 3/4 in. |
Swing | 21 in. |
Max. Distance Spindle to Table | 15-3/4 in. |
Spindle Taper | R-8 in. x tpi |
Spindle Travel | 5 in. |
Quill Diameter | 4-1/2 in. |
Number of Spindle Speeds | 6 |
Range of Spindle Speed | 65, 130, 220, 480, 925, and 1,550 Rpm |
Table Size (L x W) | 32-1/4 in. x 9-1/2 in. |
Table Longitudinal Travel | 20-1/2 in. |
T-Slots Number and Size | 4 and 5 in. x 1 in. |
Base Dimensions | 24-1/4 in. x 15-15/16 |
Length | 28 in. |
Width | 39-1/4 in. |
Height | 42-1/2 in. |
Product Weight | 628 lbs. |
Shipping Weight | 628 lbs. |
