JET J-A5816 1-Hp 115/230V 15" Variable Speed Floor Model Drill Press
by Jet
$2,529.00
+ Free Shipping
Condition: New
SKU: JET-354550
-
Product Details
-
Customer Reviews
-
Shipping & Return Policies
Spend $199 or more and receive Fast FREE Ground Shipping on your order. Plus for those of you who need your order even quicker, for spending $199 or more we pass the savings on to you by offering Discounted Express Shipping. For orders under $199, you will only pay a flat fee of $8.95. This shipping offer applies to the Continental US ONLY.
All locations outside the Continental US will receive discounted shipping, if you have any questions please feel free to contact us. Full Shipping Policy. -
People Who Bought This Also Bought
-
Similar Products
Features
- Full bearing support on quill for maximum spindle stiffness
- Handwheel speed adjustment of 400 to 5,000 RPM
- Large 2-1/4" quill for greater accuracy
- 3" column diameter for maximum head support
- 6" stroke for deep hole application
- Accurate depth stop for precice hole depths
- 1/2" drill chuck and arbor included
- Safety collar
What's in The Box
- JET J-A5816, 15" Variable Speed Floor Model Drill Press 115/230V 1PH
- Owner's Manual
Warranty
- 2-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Model | 354550 |
| UPC | 662756092687 |
| Style (Type) | Variable |
| Drills to Center of Circle (in) | 15 |
| Drilling Capacity Cast Iron (In.) | 5/8 |
| Drilling Capacity Mild Steel (In.) | 1/2 |
| Distance Column to Spindle (In.) | 7-1/2 |
| Number of Spindle Speeds | Variable |
| Range of Spindle Speeds (RPM) | 400 - 5,000 |
| Column Diameter (In.) | 3 |
| Spindle Taper (In. x TPI) | MT-2 |
| Spindle Travel (In.) | 6 |
| Spindle Distance to Base (In.) | 44-1/2 |
| Spindle Distance to Table (Max.) (In.) | 25-3/4 |
| Table Size (L x W) (In.) | 15 x 18 |
| Table Travel (In.) | 16-3/4 |
| T-Slots Number and Size (In.) | 2 and 1/2 |
| T-Slot Centers (In.) | 5-5/16 |
| Work Table Weight Capacity (Lbs.) | 90 |
| Base Dimensions (In.) | 20-7/16 x 14-3/16 |
| Base Work Table (In.) | 12-1/8 x 11-13/16 |
| Base Slots Number and Size (In.) | 2 and 1/2 |
| Motor (HP) | 1 HP, 115/230V, 1Ph |
| Overall Dimensions (L x W x H) (In.) | 30 x 20 x 71 |
| Weight (Lbs.) | 426 |
