Features
- Constructed to provide a solid base for drilling
- The enclosed spidle assembly is supported by four permanently lubricated ball bearings for greater precision and accuracy
- Cast Iron head
- Large ground steel column for maximum head and table support
- Large quill allows greater accuracy
- 3-1/8" stroke for deep hole applications
- Accurate depth stop for precice hole depths
- Table tilts 45 degree
- 5/8" drill chuck and arbor
- Telescoping safety spindle guard
What's in The Box
- JET J-2500, 15" Floor Model Drill Press 115V 1PH
- Owner's Manual
Warranty
- 2-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
Model | IDP-22 |
Sku | 354301 |
Brand | Jewt |
Style (Type) | Belt Drive |
Drills to Center of Circle (in) | 22 |
Drilling Capacity Cast Iron (in.) | 1-1/4 |
Drilling Capacity Mild Steel (in.) | 1 |
Tapping Capacity Mild Steel (in.) | 1 |
Distance Column to Spindle (in.) | 10-7/8 |
Number of Spindle Speeds | 12 |
Range of Spindle Speeds (Rpm) | 175 - 3,050 |
Column Diameter (in.) | 3-5/8 |
Spindle Taper (in. x Tpi) | MT-3 |
Spindle Travel (in.) | 4-13/16 |
Spindle Distance to Base (in.) | 48-1/2 |
Spindle Distance to Table (Max.) (in.) | 28 |
Table Size (L x W) (in.) | 18-5/8 x 16-1/8 |
T-Slots Number and Size (in.) | 2 and 5/8 |
T-Slot Centers (in.) | 3/4 |
Work Table Weight Capacity (lbs.) | 176 |
Base Dimensions (in.) | 22-5/8 x 19-7/16 |
Base Work Table (in.) | 21-1/2 x 18-5/16 |
Base Slots Number and Size (in.) | 2 and 5/8 |
Motor (Hp) | 1-1/2 |
Voltage | 115/230 |
Phase | Single |
Weight (lbs.) | 364 |
