Features
- Precision spindle roller bearings
- High quality steel hardened gears in headstock
- Lead screw cover
- Cast iron Stand
- Foot Brake comes standard
- Emergency Stop within easy reach of the Operator
- Emergency Stop within easy reach of the Operator
- Chuck Guard
- Electronic Chuck Key Docking Station, provides Operator safety as the Lathe will not turn without the chuck key being docked
- Mounted on Cast Iron stand with foot pedal, coolant, chuck key docking station ready to use
- Enclosed gearbox design provides smooth, quiet operation
- Gap bed section provided for larger diameter work
- Adjustable gibs are incorporated in the carriage and slideways
- Gearbox gives wide range of inch and metric threading and feed capabilities with few gear changes
- Compound and cross slide have backlash adjustment
- Tailstock may be offset for turning tapers and include and inch/metric graduated quill
- Spindle Spider available for ease of turning Gun barrels
What's in The Box
- 14-Inch x 37-Inch 1-Phase Geared Head Bench Lathe
- Stand
- Owner's Manual
Warranty
- 2-Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| Sku | 331440 |
| Model | GH-1440B |
| Brand | Jet |
| Voltage | 230v |
| Horsepower | 2 Hp |
| Phase | 1-Phase |
| Swing Over Bed | 14 in. |
| Swing Over Cross Slide | 8 in. |
| Swing Through Gap | 20 in. |
| Lenght of Gap | 8 in. |
| Distance Between Centers | 36-7/8 in. |
| Spindle Bore | 2 in. |
| Spindle Mount | D1-5 |
| Spindle Taper w/ Sleeve | MT6 |
| Number of Spindle Speeds | 8 |
| Range of Spindle Speeds | 70 Rpm - 1,900 Rpm |
| Number of Longitudinal
and Cross Feed Rates |
32/32 |
| Range of Longitudinal Feeds | 0.002 Ipr - 0.0548 Ipr |
| Range of Cross Feeds | 0.007 Ipr - 0.00187 Ipr |
| Number of Metric Threads | 26 |
| Range of Metric Threads | 26 |
| Range of Metric Threads | 0.4 - 7 |
| Max Tool Size | 4/5 in. x 4/5 in. |
| Compound Slide Travel | 3-1/2 in. |
| Cross Slide Travel | 7 in. |
| Carriage Travel | 37-2/5 in. |
| Tailstock Spindle travel | 4 in. |
| Taper in Tailstock Spindle | MT4 |
| Follow Rest Capacity | 0.31 in. - 2.16 in. |
| Steady Rest Capacity | 0.31 in. - 2.95 in. |
| Width of Bed | 7.32 in. |
| Length | 76-13/32 in. |
| Width | 29-29/32 in. |
| Height | 59-13/16 in. |
| Product Weight | 1,753 lbs. |
