Baileigh 1019138 WJ-85CNC 480V 3PH 60" x 98" CNC Water Jet

$185,519.00 + Free Shipping

Ships Factory Direct
This is a Built to Order item and ships from the manufacturer within 10 to 15 business days. For further assistance please call 800.629.3325
- +

Condition: New
SKU: BLH-1019138
  • Product Details

  • Customer Reviews

  • Shipping & Return Policies

    Spend $199 or more and receive Fast FREE Ground Shipping on your order. Plus for those of you who need your order even quicker, for spending $199 or more we pass the savings on to you by offering Discounted Express Shipping. For orders under $199, you will only pay a flat fee of $8.95. This shipping offer applies to the Continental US ONLY.

    All locations outside the Continental US will receive discounted shipping, if you have any questions please feel free to contact us. Full Shipping Policy.
  • People Who Bought This Also Bought

  • Similar Products

  • The WJ-85CNC water jet from Baileigh Industrial offers excellent work table accessibility on a machine built for the rigors of waterjet cutting.
  • The cutting table and framework of the WJ-85CNC is laser cut and interlocked, then welded for strength and rigidity to ensure accuracy during the cutting process.
  • The design is a cantilever design that allows for much easier material loading and unloading. This CNC water jet cutting machine also offers smoother action on the axis with exclusion of moving parts.
  • All axis ride on precision balls screws with square slide ways.
  • All slide ways are covered and protected from water for long life.
What's in The Box
  • WJ-85CNC - Coldfront Atomized Cooling Fan
  • Owner's Manual
  • 1 Year Limited Factory Warranty
  • 30 Day Satisfaction Guaranteed
Power 460V / 3-phase 60amp
Motor 40 hp
Motor KW 30kw
Working Table Size 96" x 60"
Working Table Travel (X/Y) 96"/60"
Table Size 102" x 63"
Filter Type 2 Stage/2 Filter, 10 Micron & 1 Micron
Number of Filters 2
Supported File Formats DXF
Repeatability Accuracy ± .001"
Production Pressure 56,000 psi
Max. Pump Pressure Outflow 7.92 gallons per minute
Orifice Size .014"
Travel Speed 40 fpm (26 fpm Cutting) Maximum
CNC System Windows Based
Cutting Accuracy ±.001"
Inlet Pressure 30 psi
X Axis Travel 98"
Y Axis Travel 59"
Z Axis Travel 6.75"
Hopper Capacity 250 lbs
Software BobCad Cam
Dimensions (Inches) 153x46x80, 112x73x36, 69x44x25
Weight 5600 lbs
