Features
- Best suited for grooves and cut-outs in sheet metals, tool can turn on the spot
- Cutting direction can be adjusted in three 90° steps without the need for tools
- QuickIN rapid change system for rapid, tool-free punch and die changes
- Optimum power-to-weight ratio
- Long tool life, punches can be reground
- Motor with outstanding performance and durability
- Warp-free cutting of flat and bent sheet metal
- Optimally suited for template cuts
- Chip protection mesh on vent slots
- Handle can be rotated 180°
- 16 ft. [5 m] cable
- Stainless steel up to 14 gauge [1.8 mm]
- Wide range of accessories
What's in The Box
- Cutting head
- Die (3 13 09 093 00 3)
- Punch (3 13 09 097 00 2)
- Wrench
- Carrying handle
- Owners Manual
Warranty
- 3 Year Limited Factory Warranty
- 30 Day Satisfaction Guaranteed
Specifications
| SKU | 72323012635 |
| Brand | Fein |
| Power consumption | 1,200 W |
| Power output | 750 W |
| Strokes | 750 spm |
| Cutting speed | 4.3 ft/min |
| Steel 58,000 lbf/in2 | 0.1378 [3.5] in |
| Steel 87,000 lbf/in2 | 0.0906 [2.3] in |
| Steel 116,000 lbf/in2 | 0.0709 [1.8] in |
| Non-ferrous metals up to 36,000 lbf/in2 | 0.1378 in |
| Cutting width | 9/16 in |
| Immersion Ø with die | 1-3/16 in |
| Radius of smallest curve (inside/outside) | 1/4 / in |
| Cable with plug | 16.4 ft |
| Weight | 7.72 lbs |
| Vibration and Sound Emission Values | |
| Sound pressure level LpA | 85 dB |
| Measurement uncertainty of the measured value KpA | 3 dB |
| Sound power level LWA | 96 dB |
| Measurement uncertainty of the measured value KWA | 3 dB |
| Peak sound value LpCpeak | 100 dB |
| Measurement uncertainty of the measured value KpCpeak | 3 dB |
| Vibration value 1 ahv 3-way | 8,9 m/s2 |
| Measurement uncertainty of the measured value Ka | 1,5 m/s2 |
